Model

F3

F5

F7

F9

F12

 Output Power

 8Ω per channel

2x350W

2x600W

2x800W

2x1000W

2x1300W

 4Ω per channel

2x560W

2x850W

2x1320W

2x1450W

2x1980W

 2Ω per channel

2x750W

2x1350W

2x1600W

2x1750W

2x2260W

 8Ω bridged

1100W

1700W

2640W

2800W

3960W

 4Ω bridged

1500W

2700W

3200W

3500W

4520W

 Amplifier Type

Class AB

Class H

Class H

Class H

Class H

 Input Sensitivity(8Ω)

0.775V/1.0V/1.44V

 Input Impedance

10KΩ/Unbalanced,20KΩ/Balanced

 Frequency Response

20Hz-20KHz

 THD (8Ω)

<0.03%

 Slew Rate

40V/μs

 S/N Ratio

>103dB

 Damping Factor (8Ω)

>1000

 Cooling

Dual variable speed DC fans

 Protection

Short Circuit,Thermal,Overload,Clip Limiter,DC fault protection

 Power Requirements

110/220V±10%,50/60Hz

 Dimensions (W x D x H)

483 x 449 x 89mm

483x440x132mm

 Weight

 19.5Kg

 22Kg

 24.5Kg

 27kg

 32kg

 Specifications and design are subject to change without notice
